Lathe

echoENG FTX-2000X660-TO2 DCR

- Metalworking lathe for professional use, sturdy structure with rolled and ground prismatic guides.
- Hardened sliding guides to HRC43.
- With guide shaft for automatic feed.
- Rapid longitudinal and transverse travel of intermediate slide.
- Microswitch to stop the machine when the pulley cover or spindle guard is opened.
- Claw and turret plate protection.
- Emergency stop.
- Foot brake.
- Thread indicator dial.
- Stroke stop for longitudinal carriage feed.

INCLUDED ACCESSORIES

3 jaws Chuck Ø320 mm
4 jaws Chuck Ø400 mm
Face plate Ø450 mm
Steady and Follow Rests
Chuck Guard
Work lamp
Morse taper MT5
Kit of Tools
Leadscrew cover

Digital display X-Y		yes
Voltage	V	400-F3
Power	Kw-Hp	7,5 - 10
Trasmission		Gears
Max. swing over bed	mm	660
Max. swing over cross slide	mm	420
Spindle bore	mm	105
Distance between centers	mm	2000
Taper spindle bore		113
Taper of tailstock sleeve		MT5
Diameter tailstock sleeve	mm	75
Travel tailstock sleeve	mm	150
Spindle speeds		12
Spindle speed range	R.P.M.	36-1600
Longitudinal feeds range	mm/rev	0,063-2,52
Transversal feed range	mm/rev	0,027-1,07
Rapid longitudinal feeds	m/min	4,5
Rapid transversal advances	m/min	1,9
Metric threads range	mm	22 steps / 1-14
Inch threads range	tpi	25 steps / 28-2
Diametral threads range	d.p.	24 steps / 56-4
Modular threads range	m.p.	18 steps / 0,5-7
Weight net - gross	kg	3900/4300
