Semi-Automatic Bandsaw ENG PRO BF 350 DSA TF

Description

The ENG PRO BF 350 DSA TF semi-automatic bandsaw is a professional machine designed for precise and versatile metal cutting. It offers high cutting capacity and an efficient hydraulic system, with a robust structure and user-friendly interface — ideal for workshops, metalworking facilities, and industrial environments.

Key Features

Hydraulic quick-action vice
Swivel head from 0° to 60° right and 45° left
Hydraulic cylinder-controlled descent
Dual motor speed
Integrated digital control panel
Safety microswitch on blade cover opening
Blade tension with handwheel and pressure gauge
Arm mounted on bearings with automatic return system
Fully compliant with CE standards

Technical Specifications

Model	BF 350 DSA TF
Voltage	400 V
Power	1.5 kW
Blade speed	34–68 RPM
Cutting capacity at 90° (round/square/rectangle)	Ø 270 / 260x260 / 320x180 mm
Cutting capacity at 45° right	Ø 210 / 200x200 / 220x180 mm
Cutting capacity at 60° right	Ø 135 / 130x130 / 140x100 mm
Cutting capacity at 45° left	Ø 210 / 200x200 / 220x180 mm
Vice opening	510 mm
Blade size	3660 x 27 x 0.9 mm
Weight	390 kg
Machine dimensions	1860 x 875 x 1750 mm
Product code	8243600111905

Included Accessories

Test blade

Optional Accessories: Saw Blades

Blade Model	Dimensions	TPI (teeth per inch)	Code
B 6/10	3160x27x0.9 Z6/10	2	42107600 / 8243600060243
B 8/11		2	42107600 / 8243600060245
B 5/8		2	42107600 / 8243600120174
B 4/6		2	42107600 / 8243600120175
B 3/4		2	42107600 / 8243600120176
B 2/3		2	42107600 / 8243600120244
B 1/1.4		2	42107600 / 8243600120245

Semi-Automatic Bandsaw ENG PRO BF 350 DSA TF

Description

Key Features

Technical Specifications

Included Accessories

Optional Accessories: Saw Blades

Usually available in 7/10 working days.

Terms of delivery: Ex-works. Please contact us for shipping rates.
