Description
Space-saving hydraulic cylinder with gravity return for lifting up to a maximum of 10 tonnes. Made of high quality materials.
The maximum working pressure is 700 bar and the product weight is 0.9 kg.
The table below shows the features of the OMCN jack.
Technical Specifications
Capacity 10t
Working pressure 700bar
Oil capacity 25.4cm³
Dimensions A 76mm
Dimensions B 60mm
Dimensions C 16mm
Dimensions D 40mm
Weight 0.9kg
Delivery 10-15 days
