Description
- ERGO™ bi-component grips: soft thermoplastic surface on hard polypropylene for perfect grip
- Developed in accordance with the ERGO™ science program
- Cutting capacity: Cu 2.5 mm to 3 mm, Fe 1.8 mm, Fe+ 1.4 mm to 1.6 mm
- With patented return spring with open/close function
- Half-round, knurled jaws for gripping flat and round workpieces with great accessibility in tight spaces
- Bent jaws with hardened cutting edges for cutting soft and hard wire
- High-performance alloy steel
- Phosphate finish, anti-corrosion treatment
- Conforms to standards: ISO 5745
- IP = industrial packaging
| A | B | C | D | E | F | G | Cu | Fe | Fe+ | Weight |
| 160 mm | 46 mm | 16,5 | 8,9 mm | 3 mm | 2,5 mm | 12 mm | 3 mm | 1,8 mm | 1,6 mm | 160 g |
| 200 mm | 65 mm | 17 mm | 9,4 mm | 3 mm | 2,5 mm | 12 mm | 3 mm | 1,8 mm | 1,6 mm | 170 g |
