Description
Space-saving hydraulic cylinder with gravity return for lifting up to a maximum of 5 tonnes. Made of high quality materials.
The maximum working pressure is 700 bar and the product weight is 1 kg.
The table below shows the features of the OMCN jack.
Technical Specifications
Capacity 5t
Working pressure 700bar
Oil capacity 52.8cm³
Dimensions A 155mm
Dimensions B 100mm
Dimensions C 55mm
Dimensions D 30mm
Weight 1kg
Delivery 10-15 days
