Description
Space-saving hydraulic cylinder with gravity return for lifting up to a maximum of 20 tonnes. Made of high quality materials.
The maximum working pressure is 700 bar.
The table below shows the features of the OMCN jack.
Technical Specifications
Capacity 20t
Working pressure 700bar
Oil capacity 331cm³
Dimensions A 265mm
Dimensions B 165mm
Dimensions C 100mm
Dimensions D 60mm
Weight 6,5kg
Delivery 10-15 days
