Description
Space-saving hydraulic cylinder with spring return for lifting up to a maximum of 10 tonnes. Made of high quality materials.
The maximum working pressure is 700 bar and the product weight is 1.2 kg.
The table below shows the features of the OMCN jack.
Technical Specifications
Capacity 10t
Working pressure 700bar
Oil capacity 55.6cm³
Dimensions A 115mm
Dimensions B 80mm
Dimensions C 35mm
Dimensions D 40mm
Weight 1.2kg
Delivery 10-15 days
