Description
The industrial lathe FTX-1500X400-TOP DCR 400V/F3 is designed for heavy-duty mechanical applications that require stability, precision, and high safety standards. Its extremely robust structure, built with hardened and ground prismatic guides, ensures superior rigidity and smooth carriage movement even during the most demanding machining operations.
The lathe is equipped with a dedicated leadscrew for automatic feed, ideal for prolonged and repetitive operations, improving productivity and operational continuity. Integrated safety devices include micro-switches that stop the machine when the guards are opened, chuck guard, emergency stop button, and foot brake for immediate spindle shutdown.
The thread dial indicator provides visual and precise control during threading, while the longitudinal feed stop ensures maximum accuracy in series production. Compliant with CE regulations, it is the ideal solution for mechanical workshops, maintenance departments, and industries requiring a professional, reliable, and powerful lathe.
Technical Specifications
| Feature | Value |
|---|---|
| X/Y DRO | Yes |
| Power supply | 400 V / F3 |
| Power | 5.5 – 7.5 kW / HP |
| Speed change | Gear transmission |
| Swing over bed | 400 mm |
| Swing over gap | 660 mm |
| Swing over carriage | 250 mm |
| Spindle bore | 80 mm |
| Distance between centers | 1500 mm |
| Headstock taper | MT7 |
| Tailstock taper | MT4 |
| Tailstock quill travel | 130 mm |
| Number of speeds | 12 |
| Speed range | 25 – 1800 rpm |
| Longitudinal feed | 0.04 – 2.46 mm/rev |
| Cross feed | 0.02 – 1.23 mm/rev |
| Metric threads | 24 types / 0.5 – 20 mm |
| Imperial threads | 61 types / 1-5/8 – 72 tpi |
| Diametral pitch threads | 45 types / 96 – 3-1/4 d.p. |
| Module threads | 20 types / 0.25 – 10 m.p. |
| Net/Gross weight | 2400 / 2640 kg |
| Overall dimensions | 3000 × 1150 × 1680 mm |
