Outside Micrometer 0–25 mm – Analog Mitutoyo

The 0–25 mm analog outside micrometer by Mitutoyo is a professional measuring instrument designed to ensure precision, reliability, and repeatability in dimensional inspection tasks. The built-in friction clutch guarantees consistent measurements, preventing errors caused by variations in applied measuring force.

The precision-ground hardened measuring faces and the matte chrome-plated thimble and sleeve provide clear and reliable readings, while the locking spindle ensures stability during measurements. This micrometer is ideal for machine shops, metrology laboratories, and professional applications requiring high accuracy standards.

Key Features:

• Digital / Analog: Analog

• Units: Metric

• Measuring Range: 0–25 mm

• Graduation: 0.01 mm

• Maximum Permissible Error J MPE: ±2 µm

• Flatness: 0.6 µm

• Parallelism: 2 µm

• Measuring Faces: Precision-ground hardened steel

• Spindle: Locking, Ø6.35 mm (≤300 mm), Ø8 mm (>300 mm), pitch 0.5 mm

• Scale: Matte chrome-plated thimble and sleeve, Ø 18 mm

• Measuring Force: 5–10 N

• Includes: Case, reference rod (from 25 mm), wrench, inspection certificate (0–50 mm)

• Weight: 175 g
