Description
OMCN 162/R electro-hydraulic motorised 2-speed press with automatic insertion 50 T
The electro-hydraulic press 162/R is operated by means of a lever distributor and push-button on the control panel to be operated simultaneously. Two-speed motorised control unit with automatic engagement.
The treated, chrome-plated steel cylinder rod and the steel spring inserted in the cylinder for rapid rod return, this machine is made to last, always guaranteeing excellent performance. Equipped with rear and side protection panels.
It has a 1.5kw power output of 50T and a rod speed of 3100mm/min. Supplied with calibration valves to adjust the power according to the work to be performed.
The working space is 775x1135mm.
A height-adjustable bench is included with this model. Also equipped with a large-diameter pressure gauge. Pressure gauge supplied as standard.
It has a size of 2130x850x1650mm and a weight of 560kg.
Features:
50t pressing capacity
Hydraulic drive
Power 1.5 kW
Technical specifications
Motor power 1.5kW
Pressing capacity 50t
Rod speed 3100 mm/min
Working speed 210 mm/min
A 2130mm
B 850mm
C 1650mm
D 775mm
E 1135mm
F 205mm
G 260mm
H 60mm
Weight 560kg
Delivery 10-15 days
