Description
OMCN P30/MR electro-hydraulic motorised 2-speed press with automatic insertion 30 T
The P30/MR electro-hydraulic press has a lever-type distributor and push-button on the control panel to be operated simultaneously. Two-speed motorised control unit with automatic engagement.
With a treated, chrome-plated steel cylinder rod and a steel spring inserted in the cylinder for rapid rod return, this machine is made to last, guaranteeing optimum performance at all times. Equipped with rear and side protection panels.
It has a 1.5kw power output of 30T and a rod speed of 4490mm/min. Supplied with calibration valves to adjust the power according to the work to be performed.
The working space is 695x1000mm.
A height-adjustable bench is included with this model. Also equipped with a large-diameter pressure gauge. Manometer supplied as standard.
It has a size of 2020x600x1600mm and a weight of 338kg.
Features:
30t pressing capacity
Hydraulic drive
Power 1.5 kW
Technical specifications
Motor power 1.5kW
Pressing capacity 30t
Rod speed 4490 mm/min
Working speed 300 mm/min
A 2020mm
B 600mm
C 1600mm
D 695mm
E 1000mm
F 170mm
G 260mm
H 60mm
Weight 338kg
Delivery 10-15 days
