Description
OMCN 154/MR electro-hydraulic motorised 2-speed press with automatic insertion 10 T
The electro-hydraulic press 154/MR has a lever-operated distributor and push-button on the control panel to be operated simultaneously. Two-speed motorised control unit with automatic engagement.
The treated and chrome-plated steel cylinder rod and the steel spring inserted in the cylinder for rapid rod return, this machine is made to last, always guaranteeing excellent performance. Equipped with rear and side protection panels.
It has a power output of 0.750kw capable of generating 10T and a rod speed of 5300mm/min. Supplied with calibration valves to adjust the power according to the work to be performed.
The working space is 520x980mm.
An adjustable height bench is included with this model. Also equipped with a large-diameter pressure gauge. Pressure gauge supplied as standard.
It has a size of 1910x500x100mm and a weight of 194kg.
Features:
10t pressing capacity
Hydraulic drive
Power 0.75 kW
Technical specifications
Motor power 0.75kW
Pressing capacity 10t
Rod speed 5300 mm/min
Working speed 350 mm/min
A 1910mm
B 500mm
C 1100mm
D 520mm
E 980mm
F 120mm
G 260mm
H 40mm
Weight 194kg
Delivery 10-15 days
