Centre drill for countersink angle 60° DIN 333 type A Ø (0,5-10)mm - ILIX

IlixSKU: 232_013_IL6290___232_013_IL62901
Ø Drill bit (mm): 1 mm - IL62901
Price:
$15.00
Availability : 1
Register to buy

Description

60° COUNTERSINK ANGLE - GENERIC APPLICATIONS - DIN 333 A - CATALOGUE 6290

Material: HSS

Ø L1 D2
0,5 20 3,15
1 31,5 3,15
1,25 31,5 3,15
1,6 35,5 4
2 40 5
2,5 45 6,3
3,15 50 8
4 56 10
5 63 12,5
6,3 71 16
10 100 25
