Overview

MAXIMA 160 SYNERGIC

code 816085

Microprocessor controlled MIG-MAG/FLUX/BRAZING inverter wire welding machine. It allows great versatility in the use of various types of materials (steel, stainless steel, aluminium) and in all possible applications, from maintenance to installation works.
The SYNERGIC adjustment of the welding parameters makes the products easy to use and grants excellent results, always, also for the less experienced operator.
Light and compact, it can be easily carried in any intervention place, both inside and outside.
Features:
- Polarity reversal for GAS MIG-MAG/BRAZING welding
- Thermostatic, overvoltage, undervoltage, motorgenerator (+/- 15%) protections.
Fit for NO GAS/Flux welding, it can be transformed into MIG-MAG with the optional kit.
Complete with MIG-MAG torch, work clamp and cable.

Technical data

POWER FACTOR 0,7

SINGLE PHASE MAINS VOLTAGE 230 V

STEEL WELDING WIRE DIAMETER 0,6 - 0,8 mm

MAINS FREQUENCY 50 / 60 Hz

INOX WELDING WIRE DIAMETER 0,8 mm

CURRENT RANGE 20 - 150 A

ALUMINIUM WELDING WIRE DIAM. 0,8 - 1 mm

MAX CURRENT 115 @ 20% A

FLUX CORED WELDING WIRE DIAM. 0,8 - 1,2 mm

DC CURRENT 65 A

BRAZING WIRE DIAM. 0,8 mm

MAX NO LOAD VOLTAGE 44 V

PROTECTION DEGREE IP23

MAX ABSORBED CURRENT 18 A

DIMENSIONS 45 X 23,5 X 37 cm

ABSORBED CURRENT AT 60% 9 A

WEIGHT 9,29

MAX ABSORBED POWER 2,6 kW

EAN CODE 800489797599 3

ABSORBED POWER AT 60% 1,2 kW

PIECES/PALLET 18 pz/pallet

MAINS FUSE 16 A

PIECES/PALLET - B 12 pz/pallet B

EFFICIENCY 86 %

Accessories

Included Accessories

CABLE 16 MMQ 1,8 M 124502

TW160 MIG TORCH 2M 742402

COLORADO 150B WORK CLAMP 150A 712001
