Metal Lathe FTX-3000X660-TOP DCR 400V
The FTX-3000X660-TOP DCR is a professional lathe designed for high-precision mechanical machining on large workpieces. Its rigid structure, featuring laminated and ground prismatic guides and a hardened carriage, ensures smooth movement, constant accuracy, and long-term durability even under heavy loads.
With a distance between centers of 3000 mm and a maximum swing over bed of 660 mm, this lathe is ideal for machining shafts, cylinders, pipes, and large components, making it suitable for mechanical workshops, heavy fabrication, and advanced industrial applications.
Powered by a 10 HP motor with 400 V three-phase supply and equipped with a 12-speed transmission, it offers a wide rotation range from 36 to 1600 rpm. This allows both high-torque roughing operations and extremely precise finishing work.
The lathe features automatic longitudinal and cross feed, with a smooth-running carriage and robust slides ensuring full control during machining. The safety system includes an emergency stop, safety micro-switches on guards, a foot brake, and ergonomic controls for safe and comfortable operation.
The standard equipment includes a chuck, tailstock, steady rest, spindle guard, threading dial, and end-of-travel stops, making the machine ready for a broad range of operations such as external and internal turning, threading, taper turning, facing, and complex machining tasks.
The FTX-3000X660-TOP DCR is the ideal choice for users who require a reliable, powerful, and versatile lathe suitable for industrial production and professional machining of large workpieces.
Technical Specifications
| Feature | Value |
|---|---|
| X/Y coordinate display | Yes |
| Power supply | 400 V / 3-Phase |
| Motor power | 7.5 – 10 kW-HP |
| Speed change system | Gear transmission |
| Swing over bed | 660 mm |
| Swing over gap | 870 mm |
| Swing over cross slide | 420 mm |
| Spindle bore diameter | 113 mm |
| Distance between centers | 3000 mm |
| Headstock taper | 1:20 |
| Tailstock taper | MT5 |
| Tailstock diameter | — |
| Tailstock quill travel | 150 mm |
| Number of speeds | 12 |
| Speed range | 36 – 1600 rpm |
| Longitudinal feed range | 0.063 – 2.52 mm/rev |
| Cross feed range | 0.027 – 1.07 mm/rev |
| Rapid feed, longitudinal (intermediate carriage) | 4500 mm/min |
| Rapid feed, cross (intermediate carriage) | 1900 mm/min |
| Metric thread range | 22 types / 1 – 14 mm |
| Inch thread range | 26 types / 28 – 2 tpi |
| Diametral pitch threads | 24 types / 56 – 4 d.p. |
| Modular threads | 18 types / 0.5 – 7 m.p. |
| Net / gross weight | 3800 / 4200 kg |
| Machine dimensions | 4650 × 1150 × 2060 mm |
