Description
HSS die for Whitworth thread cutting BSW, DIN 223.
Model UT 10 FW00 Specifications:
Size Inches 1/8"
Pitch TPI 40
External Diameter mm 20
Thickness mm 5
Model UT 10 FW01 Specifications:
Size Inches 1/4"
Pitch TPI 20
External Diameter mm 20
Thickness mm 7
Model UT 10 FW02 Specifications:
Size Inches 3/8"
Pitch TPI 16
External Diameter mm 30
Thickness mm 11
Model UT 10 FW03 Specifications:
Size Inches 1/2"
Pitch TPI 12
External Diameter mm 38
Thickness mm 14
Model UT 10 FW04 Specifications:
Size Inches 5/8"
Pitch TPI 11
External Diameter mm 45
Thickness mm 18
Model UT 10 FW05 Specifications:
Size Inches 3/4"
Pitch TPI 10
External Diameter mm 45
Thickness mm 18
Model UT 10 FW06 Specifications:
Size Inches 7/8"
Pitch TPI 9
External Diameter mm 55
Thickness mm 22
Model UT 10 FW07 Specifications:
Size Inches 1"
Pitch TPI 8
External Diameter mm 55
Thickness mm 22
Model UT 10 FW08 Specifications:
Size Inches 1-1/8"
Pitch TPI 7
External Diameter mm 65
Thickness mm 25
Model UT 10 FW09 Specifications:
Size Inches 1-1/4"
Pitch TPI 7
External Diameter mm 65
Thickness mm 25
Model UT 10 FW10 Specifications:
Size Inches 1-3/8"
Pitch TPI 6
External Diameter mm 65
Thickness mm 25
Model UT 10 FW11 Specifications:
Size Inches 1-1/2"
Pitch TPI 6
External Diameter mm 75
Thickness mm 26
Model UT 10 FW12 Specifications:
Size Inches 1-5/8"
Pitch TPI 5
External Diameter mm 75
Thickness mm 26
Model UT 10 FW13 Specifications:
Size Inches 1-3/4"
Pitch TPI 5
External Diameter mm 90
Thickness mm 27
Model UT 10 FW14 Specifications:
Size Inches 1-7/8"
Pitch TPI 4-1/2
External Diameter mm 90
Thickness mm 27
Model UT 10 FW15 Specifications:
Size Inches 2
Pitch TPI 4-1/2
External Diameter mm 90
Thickness mm 27
