Description
HSS die for cylindrical thread cutting, DIN 5158.
Model UT 10 FT00 Specifications:
Size Inches G1/8
Pitch TPI 28
Ø mm 30
Thickness mm 11
Model UT 10 FT01 Specifications:
Size Inches G1/4
Pitch TPI 19
Ø mm 38
Thickness mm 10
Model UT 10 FT02 Specifications:
Size Inches G3/8
Pitch TPI 19
Ø mm 45
Thickness mm 14
Model UT 10 FT03 Specifications:
Size Inches G1/2
Pitch TPI 14
Ø mm 45
Thickness mm 14
Model UT 10 FT04 Specifications:
Size Inches G5/8
Pitch TPI 14
Ø mm 55
Thickness mm 16
Model UT 10 FT05 Specifications:
Size Inches G3/4
Pitch TPI 14
Ø mm 55
Thickness mm 16
Model UT 10 FT06 Specifications:
Size Inches G7/8
Pitch TPI 14
Ø mm 65
Thickness mm 18
Model UT 10 FT07 Specifications:
Size Inches G1
Pitch TPI 11
Ø mm 65
Thickness mm 18
Model UT 10 FT08 Specifications:
Size Inches G1-1/8
Pitch TPI 11
Ø mm 75
Thickness mm 20
Model UT 10 FT09 Specifications:
Size Inches G1-1/4
Pitch TPI 11
Ø mm 75
Thickness mm 20
Model UT 10 FT10 Specifications:
Size Inches G1-1/2
Pitch TPI 11
Ø mm 90
Thickness mm 20
